Antenna: Service and Repair

ANTENNA

Removal and Installation

1. Remove the antenna mast from the antenna base.

2. Remove the antenna base.

1

Remove the radio antenna base cap.

2

Remove the 3 screws.

3

Lift the antenna base.

4

Disconnect the antenna lead-in cable from the antenna base and remove the antenna base.

3. Remove the fender splash shield.

1

Remove the 3 screws.

2

Remove the pushpin and the fender splash shield.

4. Push the (A) antenna lead-in cable and the (B) grommet into the passenger compartment.
