E 450 V10-6.8L (2008)
Shift Cable: Adjustments
Selector Lever Cable Adjustment
1. With the vehicle in NEUTRAL, position it on a hoist.
2. Place the selector lever in the (D) position.
^
Place a 1.3 kg (3 lb) weight on the selector lever.
3. Disconnect the selector lever cable from the manual lever.
4. Unlock the lock tab on the selector lever cable.
5. For either automatic transmission, place the manual control lever in the (D) position.
1) Place the manual control lever in the 1st gear position.
2) Move the manual control lever 2 detents to the (D) position for the 4R70E/4R75E transmission. Move the manual control lever 3 detents to the
(D) position for the TorqShift transmission.
6. Connect the selector lever cable to the manual control lever.
