Escort L4-110 1.8L DOHC (1994)
Front Stabilizer Bar Removal
NOTE: The engine and transaxle mounts will support the chassis frame when unbolting the chassis frame from the vehicle frame.
11. Unbolt the stabilizer bar from the chassis frame and remove the stabilizer bar from the vehicle.
Installation
Front Stabilizer Bar Installation
1. Position the stabilizer bar into the vehicle.
2. Secure the stabilizer bar to the chassis frame with bolts. Tighten the bolts to 43-59 N.m (32-43 lb4t).
3. Position the chassis frame to the vehicle frame. Tighten the mounting bolts and nuts to 93-127 N.m (69-93 lb-ft).
Front Stabilizer Bar Removal
4. Position the crossmember to the vehicle frame and the transaxle mounts. Tighten the bolts and nuts as shown.
