Explorer 2WD V6-4.0L VIN E (2001)

Page 1
background image

Clutch Disc: Specifications



O.S. Diameter (approx.)

10.2 in







I.S. Diameter (approx.)

7.3 in







Facing Area Sq. cm (sq. in)

508 (787)







Compressed Thickness

0.307 in







Lining Material

Woven non-asbestos
