Explorer 2WD V6-4.0L VIN E (2001)

Page 1
background image

Flex Plate: Specifications



Flywheel Bolts

Stage 1

13 Nm (10 ft.lbs.)

Special bolts are used for flywheel installation; do not



use standard bolts.











Stage 2

71 Nm (52 ft. lbs.)
