Explorer AWD V8-4.6L (2010)
Keyless Entry Key-Pad: Testing and Inspection
Keyless Entry Keypad Code Programming
NOTE: A maximum of 3 personal entry codes can be programmed into the vehicle. The personal entry codes can be associated with up to two memory
seat/adjustable pedal settings.
1. Enter the permanent factory keyless entry keypad code.
2. Press the 1/2 button within 5 seconds to activate the programming mode. Holding the 1/2 button for more than 2 seconds after activation erases all
the stored customer codes. The existing codes do not need to be erased to program a new code.
3. Within 5 seconds, enter the new 5-digit keyless entry keypad code.
4. Press the 1/2, 3/4, or 5/6 to indicate which of the 3 personal entry code positions is to be programmed.
5. The door locks lock and unlock to confirm the new code is programmed.
6. To program an additional personal entry code, repeat Steps 2 through 4.
