F 150 2WD Pickup V8-4.6L SOHC VIN W (1998)
Brake Rotor/Disc: Specifications
Brake Rotor/Disc
Updated Information Per TSB 99-25-6
Rear Brakes
Rear Brake Disc
Minimum Thickness .................................................................................................................................................................... 0.44" in. ( 11.00 mm. )
Runout ............................................................................................................................................................................................................. 0.0024" in.
Thickness Variation ......................................................................................................................................................................................... 0.0005" in.
Rotor Dimensions
Minimum Thickness E 150 Heavy Duty ....................................................................................................................................................................... 1.1 in
Minimum Thickness E 150/Lighting ............................................................................................................................................................................. .98 in
Brake Disk Maximum Runout .................................................................................................................................................................................. 0.003 in.
Brake Disk Maximum Thickness Variation ........................................................................................................................................................... 0.0004 in.
