F 150 4WD Pickup V8-351 5.8L VIN G 2-bbl (1984)
Choke Pull-off: Adjustments
Fig. 11 Dechoke adjustment
1.
Hold throttle in wide open throttle position.
2.
Apply a light closing pressure on the choke plate and measure the gap between the lower edge of the choke plate and air horn wall.
3.
To adjust, bend the pawl on the fast idle lever, Fig. 11, forward to increase or backward to decrease the clearance.
