F 150 4WD Pickup V8-5.4L SOHC VIN 3 (1999)
Diagnostic Connector - ABS: Locations
NOTE: There are TWO diagnostic test connectors in this system. Ford uses varying terminology for these connectors but you can identify them by
connector number and by location.
-
The first test connector is the black RABS Diagnostic Test Connector C207. This primary test connector is used to retrieve and clear codes.
RABS Data Link Connector Location
RABS Data Link Connector C207 is located behind the right side of the Instrument Panel.
