F 350 2WD Super Duty V10-6.8L (2009)
Alignment: Service and Repair
Toe Adjustment
Toe Adjustment - F-250 and F-350 Rear Wheel Drive (RWD)
1. Using alignment equipment and the manufacturer's instructions, measure the toe settings.
-
Refer to Alignment Specifications in the Specifications for optimal alignment settings.
-
If the toe settings are not within specification, go to the next step.
2. Start the engine and center the steering wheel.
3. Turn the engine off and, using a suitable steering wheel holding device, lock the steering wheel in the straight ahead position.
4. Loosen the tie-rod adjuster sleeve nuts.
5. Rotate the tie-rod adjusting sleeves to obtain the correct toe setting.
6. Position both adjusting sleeve clamp openings downward within 45 degrees of vertical. Tighten the nuts to 55 Nm (41 lb-ft).
7. Verify the toe settings and adjust as necessary.
