F 350 2WD Super Duty V10-6.8L (2009)
Hose/Line HVAC: Service and Repair
Suction Accumulator to Compressor Line
Suction Accumulator to Compressor Line
NOTE: 6.4L diesel shown, 5.4L and 6.8L similar.
Removal and Installation
All vehicles
1. Recover the refrigerant.
6.4L diesel vehicles
2. Remove the Air Cleaner (ACL) and ACL outlet tube.
5.4L or 6.8L vehicles
3. Detach the suction accumulator-to-compressor line bracket bolt.
4. Detach the wire harness clip at the suction accumulator outlet fitting.
All vehicles
