Focus ZTS L4-2.0L DOHC VIN 3 (2001)
Timing Belt: Diagrams
-
Crankshaft at TDC on cylinder number 1.
-
Cylinders No 1 and No 4 are at TDC when the Woodruff key points straight up.
