Fusion FWD L4-2.3L VIN Z (2007)
All vehicles
12. Remove the 3 steering gear mounting bolts.
-
To install, tighten to 107 Nm (79 lb-ft).
13. NOTE: The steering gear is not removed with the front subframe and must be positioned aside.
Position the steering gear aside using mechanic's wire.
14. Remove the 2 (one each side) lower stabilizer bar link nuts and separate from the stabilizer bar.
-
To install, tighten to 42 Nm (31 lb-ft).
15. Remove the RH and LH lower ball joint nuts.
-
To install, tighten to 200 Nm (148 lb-ft).
