Fusion FWD L4-2.3L VIN Z (2007)
4. Remove the bolt and the radio frequency interference capacitor.
^
To install, tighten to 10 Nm (89 inch lbs.).
5. Remove the engine mount bracket bolt.
^
To install, tighten to 115 Nm (85 ft. lbs.).
6. Use the special tool to raise the engine 25 mm (0.98 inch).
7. Remove the 2 engine mount bracket nuts.
^
To install, tighten to 103 Nm (76 ft. lbs.).
8. Remove the nut, 2 bolts and the engine mount.
^
To install, tighten to 55 Nm (41 ft. lbs.).
9. NOTE: If the engine mount bracket is to be removed, the engine must be lowered to avoid contact between the A/C tubes and the engine mount
bracket.
Use the special tool to lower the engine 25 mm (0.98 inch).
^
Remove the engine mount bracket.
10. To install, reverse the removal procedure.
