Fusion FWD L4-2.3L VIN Z (2007)
2. Remove the 4 screws and position the RH fender splash shield aside.
3. Remove the 6 pin-type retainers (4 shown) and the RH splash shield.
4. Remove the cylinder block plug.
5. Turn the crankshaft pulley bolt to position the No. 1 cylinder at top dead center (TDC) and install the special tool.
6. Disconnect the crankshaft position (CKP) sensor electrical connector.
7. Remove the bolts and discard the CKP sensor.
Installation
