Mustang V8-302 5.0L CFI HO (1985)
8.
Install door alignment pin catch and door alignment pin catch plate on each door "B" pillar with bolts provided, Figures 3 and 4.
9.
Make any necessary adjustments to the door alignment pin catch and door alignment pin catch plate.
10.
Reinstall both interior quarter trim panels.
11.
Reinstall both interior door trim panels.
FIGURE 5
12.
Install replacement "VIN" label on left "B" pillar below striker, Figure 5.
Convertible Door Alignment Procedure
NOTE:
Standard pop rivet guns with regular tips cannot be used. A pneumatic hydraulic rivet gun, Rotunda Tool 107-00608 or equivalent must be
used.
1.
Raise vehicle on hoist.
2.
Position four (4) jack stands under the vehicle.
