Mustang V8-302 5.0L CFI HO (1985)
Oil Level Warning Indicator: Customer Interest
Low Oil Level Indicator Lamp - Comes On or Flickers
Article No. 85-6-3
WARNING LIGHT - LOW OIL LEVEL INDICATOR - COMES ON OR FLICKERS WITH SATISFACTORY OIL LEVEL ON 3.8L & 5.0L
ENGINES
FORD 1985 CROWN VICTORIA, THUNDERBIRD, LTD, MUSTANG
LINCOLN-MERCURY 1985 MARK VII, CONTINENTAL, LINCOLN TOWN CAR, GRAND MARQUIS, COUGAR, MARQUIS, CAPRI
The low oil level sensor, installed on vehicles built between December 17, 1984 through February 2, 1985, may have low electrical resistance through
the sensor (100K OHM or less). At 100K OHM or less the sensor will illuminate the low oil level light regardless of oil level in the engine.
Service technicians should follow the diagnostic procedure outlined in Section 33-40, Volume B, of the 1985 Car Shop Manual, to determine whether or
not the oil level sensor is at fault.
All suspect production and service parts have been removed and replaced with new parts. The new certified parts are identified with a yellow dot.
Low Oil Level Sensor Date Coding - Suspect Sensors Date Coded 15M4 Through 18A5
Figure 2 - Sensor Date Coding
The low oil level sensors have a build date stamped on the end washer (See Figure 2).
PART NUMBER
PART NAME
CLASS
E4AZ-6C624-A
Low Oil Level Sensor
R
WARRANTY STATUS: Reimbursable within the provisions of the Warranty and Policy Manual.
OPERATION: SP6624A85
TIME:
0.3 Hr. DLR. CODING: Basic Part No. 6C624 - Code: 46
