Ranger 2WD V6-177 2.9L (1989)
FIGURE 2
6.
Grind out and throw away the existing door glass slide from the regulator drive arm, Figure 1.
7.
Grind out and throw away the two (2) existing door glass bracket slides, Figure 2.
8.
Install a new door glass slide, (E9TZ-1023240-A) in the regulator drive arm. Stake the slide with a hammer, Figure 1.
9.
Install two (2) new door glass bracket slides, (E9TZ-10234B36-A) in the glass bracket. Tighten the retaining nuts to a torque of 5-8 ft.lbs. (7-11
N-m), Figure 2.
10.
Apply a liberal amount of Ford Multi-Purpose Grease, (DOAZ-19584-AA) along the channel of the existing door glass guide and door glass
bracket.
11.
Position the door glass bracket to the glass and install two (2) blind rivets, (385323-S100).
12.
Reinstall the door glass regulator. Use three(3)rivets, (385189-S100) to secure manual door glass regulators. Use four (4) rivets, (385189-S100) to
secure power door glass regulators.
