Taurus X AWD V6-3.5L (2009)
Sunroof / Moonroof Windguard: Service and Repair
Air Deflector
Air Deflector
Removal and Installation
1. Place the roof opening panel glass in the full OPEN position.
2. From top of vehicle, depress spring steel locating tab downward on each side with flat-blade screwdriver while pushing deflector toward rear of
vehicle.
-
To install, make sure locating tabs are firmly locked in place.
3. Tilt the air deflector upward and pull forward to remove.
4. To install, reverse the removal procedure.
-
Initialize the roof opening panel motor. For additional information, refer to Roof Opening Panel Motor Initialization See: Testing and
Inspection/Programming and Relearning.
