C 3500 HD Truck 2WD V8-6.5L DSL Turbo VIN F (2001)
Passenger Assist Handle: Service and Repair
Assist Handle Replacement (Pickup)
Removal Procedure
1. Remove the handle screw covers using a small flat-bladed prying device.
2. Remove the screws.
3. Remove the handle.
Installation Procedure
1. Install the handle.
Notice: Refer to Fastener Notice in Service Precautions.
2. Install the handle screws.
Tighten the handle screws to 6 N.m (53 lb in).
3. Install the handle screw covers by pushing the covers into place.
