C 3500 HD Truck 2WD V8-6.5L DSL Turbo VIN F (2001)
Door Lock Cylinder: Service and Repair
Door Lock Cylinder Replacement
Removal Procedure
1. Raise the window completely.
2. Remove the front door trim panel.
3. Remove the water deflector.
4. Remove the outside door handle (3).
5. Remove the clip that retains the lock cylinder lever to the lock cylinder (1).
6. Press the lock cylinder retainer.
Installation Procedure
1. Press the lock cylinder (1) in the outside door handle (3) in order to engage the lock cylinder retainer.
2. Install the clip in order to retain the lock cylinder lever to the lock cylinder (1).
3. Install the outside door handle (3).
4. Install the front door water deflector.
5. Install the front door trim panel.
