Canyon 4WD L5-3.7L (2007)
Accelerator Pedal Position Sensor: Locations
Engine Controls Component Views
Left Side of I/P
Left Side of I/P
1 - C275 (Body Harness to Steering Wheel Harness)
2 - A/T Shift Lock Control Solenoid Connector
3 - Body Harness
4 - Accelerator Pedal Position (APP) Sensor Connector
5 - Accelerator Pedal
6 - Accelerator Pedal Position (APP) Sensor
7 - A/T Shift Lock Control Solenoid
8 - Ignition Lock Cylinder Case (Ignition Switch Location)
