Canyon 4WD V8-5.3L (2009)
Front Door Exterior Handle: Service and Repair
Front Side Door Outside Handle Replacement
Removal Procedure
1. Remove the front door trim panel. Refer to Front Side Door Trim Panel Replacement (See: Front Door Panel/Service and Repair).
2. Remove the front door water deflector. Refer to Front Side Door Water Deflector Replacement (See: Front Door Panel/Service and Repair).
3. Disconnect the outside door handle rod by releasing the retaining clip (2).
4. Disconnect the lock cylinder rod by releasing the retaining clip (1).
5. Remove the bolts retaining the outside door handle to the door.
6. Remove the outside door handle from the door.
7. Remove the lock cylinder from the outside door handle. Refer to Front Side Door Lock Cylinder Replacement (See: Locks/Door Locks/Door
Lock Cylinder/Service and Repair).
