S15/T15 2WD Jimmy V6-262 4.3L (1991)
1. Seal (57) to the compressor.
-
Dip the seal (57) in 525 viscosity refrigerant oil.
2. Valve (56) to the compressor
Tighten
-
Valve (56) to 19 N.m (14 ft.lbs).
