S15/T15 2WD Jimmy V6-262 4.3L (1991)

Page 1
background image

Clutch Start Switch: Locations

Rear Of Instrument Cluster.

 Below LH Side Of I/P, On Clutch Pedal Support

Applicable to:  S10, S15 & Sonoma
