S15/T15 2WD Jimmy V6-262 4.3L VIN W CPI (1993)
Removing And Installing Shaft Seal O-Ring
7. Remove and discard the seal seat O-ring from the compressor neck using O-ring remover J 9553-01.
8. Recheck the shaft and inside of the compressor neck for dirt or foreign material and be sure these areas are perfectly clean before installing new
parts.
Clean
-
Thoroughly clean O-ring seal groove in front head.
