S15/T15 2WD Jimmy V6-262 4.3L VIN W CPI (1993)
Fuel Level Sending Unit: Service and Repair
Fuel Pump And Sender Assembly (Typical)
REMOVE/DISCONNECT
-
Negative battery cable.
-
Raise vehicle.
-
Fuel tank.
-
Pump and sending unit assembly by turning cam lock counterclockwise using tool J-36608 or J-24187 or equivalent.
Pull fuel pump up into attaching hose while pulling outward from the bottom support.
Do not damage rubber insulator or strainer.
INSPECT
-
Inspect fuel pump attaching hose for signs of deterioration.
-
Inspect rubber sound insulation at bottom of pump for deterioration.
INSTALL/CONNECT
-
Pump assembly into attaching hose.
NOTE Care should be taken not to fold over or twist strainer when installing sending unit as this will restrict fuel flow.
-
Sending unit and fuel pump assembly into fuel tank. (Always use a new O-ring seal).
-
Cam lock assembly. Turn cam lock clockwise to lock it.
-
Fuel tank assembly.
-
Negative battery cable.
-
START vehicle and check for fuel leaks.
-
Lower vehicle.
