Savana 3500 V8-6.6L DSL Turbo VIN 6 (2007)
Steering Column: Service and Repair
Lower Bearing and Steering Column Jacket Replacement (Column Shift Tilt)
Lower Bearing and Steering Column Jacket Replacement (Column Shift Tilt)
Tools Required
*
J 21854-01 Pivot Pin Remover
*
J 41688 Centering Sphere Installer-Tilt Steering Wheel
Removal Procedure
Caution: Refer to SIR Caution .
1. Disable the SIR system. Refer to SIR Disabling and Enabling .
2. Remove the shift lever assembly.
3. Remove the ignition lock cylinder.
4. Remove the ignition lock cylinder case.
5. Remove the tilt spring assembly only.
6. Inspect the steering column for accident damage.
7. Remove the 2 pan head tapping screws from the turn signal and multifunction switch assembly.
8. Remove the turn signal and multifunction switch assembly.
Notice: Do not use excessive force when removing the automatic transmission shift lock control from the steering column. Using excessive force
may cause damage to the automatic transmission shift lock control and/or the steering column.
9. Remove the A/T shift lock control using the following procedure:
