Terrain AWD L4-2.4L (2010)
PCV Valve Hose: Service and Repair
Positive Crankcase Ventilation Hose/Pipe/Tube Replacement
Removal Procedure
1. Remove the intake manifold cover. Refer to Intake Manifold Cover Replacement (See: Engine, Cooling and Exhaust/Engine/Intake
Manifold/Service and Repair/Intake Manifold Cover Replacement).
2. Remove the PCV hose (1) from the camshaft cover.
Installation Procedure
1. Install the PCV hose (1) to the camshaft cover.
2. Install the intake manifold cover. Refer to Intake Manifold Cover Replacement (See: Engine, Cooling and Exhaust/Engine/Intake
Manifold/Service and Repair/Intake Manifold Cover Replacement).
