Yukon Denali 4WD V8-6.0L Hybrid (2011)
Refrigerant Pressure Sensor / Switch: Locations
A/C Refrigerant Pressure Sensor
Engine Compartment Components
Front of Vehicle/Engine Compartment Component Views
Engine Compartment Components
1 - Mass Air Flow (MAF)/Intake Air Temperature (IAT) Sensor
2 - Battery (except HP2)
3 - Fuse Holder (except HP2)
4 - A/C Low Pressure Sensor (HP2)
5 - Battery (HP2)
6 - A/C Refrigerant Pressure Sensor (except HP2)
7 - A/C Refrigerant Pressure Sensor (HP2)
Front of Engine Compartment Components
Front of Vehicle/Engine Compartment Component Views
