Unibody: Customer Interest
Body - Kick Panel Water Leak

Model

Applicable To

PRELUDE

1988-1991

ACCORD

1990-1991

File Under

Bulletin No.
91-023

BODY

Issue Date

JULY 26, 1991

Water Leak from Kick Panel

SYMPTOM

Wet carpet in the kick panel area.

PROBABLE CAUSE

^

Insufficient sealer in the wheel house area.

^

Improperly seated grommets and/or excessive sealer under the grommet flanges.

CORRECTIVE ACTION

1.

Have an assistant direct water at the adjoining points of the "A" pillar, windshield and the fender.
