Civic CX Hatchback L4-1590cc 1.6L SOHC MFI (1997)
Hose/Line HVAC: Mechanical Specifications
Discharge hose to the compressor
9.8 Nm
6 x 1.00 mm
Discharge hose to the condenser
9.8 Nm
Condenser pipe to the condenser
9.8 Nm
Condenser pipe to the receiver/dryer
9.8 Nm
Receiver pipe A to the receiver/dryer
9.8 Nm
Receiver pipe B to the receiver pipe A 13 Nm
Receiver pipe C to the receiver pipe B 13 Nm
Receiver pipe C to the Evaporator
9.8 Nm
Suction pipe B to the Evaporator
9.8 Nm
Suction pipe A to the Suction pipe B
31 Nm
Suction hose to the Suction pipe A
31 Nm
Suction hose to the Compressor
9.8 Nm
