Santa Fe L4-2.4L (2001)
NOTE:
For 1999-2001 Sonata or 2001 Elantra, XG or Santa Fe, refer to the Automatic Transaxle Overhaul Manual, Page 45D-51, to locate the related
solenoid.
10.
Clear the codes and test drive the vehicle for two driving cycles (two key-on to key-off driving cycles, including 1-2-3-4 upshifts and 4-3-2-1
downshifts). If the DTC return, replace the TCM.
DTC INFORMATION:
For your reference, the logic the TCM uses to set solenoid codes are listed.
DO NOT replace the transaxle for those codes listed as "Electrical Condition". Refer to the tables for additional information.
TCM DTC - 1999-01 SONATA, 2001 ELANTRA, XG & SANTA FE
2000-01 ACCENT, 1999-00 ELANTRA (produced after 6/1/99):
TCM DTC - 1996-99 ELANTRA/TIBURON (PRIOR TO 6/1/99), & 1996-99 ACCENT:
