Memory Positioning Module: Service and Repair
Driver Seat Control Unit

Removal and Installation

DRIVER SEAT CONTROL UNIT

Removal and Installation

REMOVAL

CAUTION:
When removing and installing, use shop cloths to protect parts from damage.

1. Remove driver seat (1).  See: Seats/Service and Repair/Front Seat/Removal and Installation.
2. Remove mounting bolts (A).
3. Remove driver seat control unit (2).

INSTALLATION
Install in reverse order of removal.

CAUTION:
Be sure to clump the harness to the right place.

NOTE:
After installing driver seat, perform additional service when replacing control unit.  See: Testing and Inspection/Programming and
Relearning/Additional Service When Replacing Control Unit/Special Repair Requirement.

Exploded View

DRIVER SEAT CONTROL UNIT

Exploded View

 See: Seats/Service and Repair/Front Seat/Exploded View.
