i-350 L5-3.5L (2006)
Power Window Switch: Technical Service Bulletins
Interior - Door Switch Removal Precautions
Information IB08-11-S003
Issue Date: FEBRUARY 2008
Information To Avoid Damage Or Breakage To Power Mirror/Window/Lock Switch Trim Plate Assembly During Removal From Door Trim
Affected Vehicles
2007-2008 Isuzu i-290/i-370 (TI)
2006 Isuzu i-280/i-350 (TI)
Service Information
When servicing any components that require the removal of the door trim panel and/or the power mirror, window, and door lock switch plate assembly,
the following steps should be taken to avoid damaging or breaking the clip tower, which holds the plate to the door panel in the front.
1.
Remove the two screws securing the switch plate assembly to the door trim panel.
2.
Lift the front of the plate up to disengage the clip.
If lifting the rear of the assembly first, it will break the clip tower.
This information can be found in Service Manual under Mirror, Window, and Door Lock Switch Replacement.
