NPR L4-5.2L DSL Turbo (2005)
-
Check that the round alignment mark (white paint) is positioned as shown in the illustration when viewed from the plug hole. If
necessary, reposition the gear.
-
Tighten the stud bolts and the nuts to the specified torque.
Tightening torque
nut: 50 N.m (37 lb ft)
bolt: 76 N.m (56 lb ft)
10. Apply a light coat of engine oil to the O-ring.
11. Install the oil drain adapter to the plug hole. Tighten the bolt to the specified torque.
Tightening torque: 8 N.m (6.9 lb ft)
12. Connect the fuel temperature sensor and the suction control valve connectors to the fuel supply pump.
13. Install the fuel feed hose.
14. Install the throttle assembly.
-
Coat the fluid gasket and mount within 7 minutes.
