Rodeo LSE 4WD V6-3.2L (2000)
Exhaust Pipe: Service and Repair
Forked Exhaust Pipe
Forked Exhaust Pipe
Removal
1. Disconnect battery ground cable.
2. Lift up the vehicle and support with suitable safety stands.
3. Remove the forked exhaust pipe fixing bolts & nuts (1) (3) (5) and the exhaust silencer fixing nuts (4), then remove the forked exhaust pipe (2).
Installation
1. Install the forked exhaust pipe (2), and tighten the fixing bolts (1) (5) and the nuts (3) (4) to the specified torque.
Torque
Bolts & nuts: 43 Nm (32 ft. lbs.)
Nuts: 43 Nm (32 ft. lbs.)
