Rodeo LSE 4WD V6-3.2L (2000)
5. Remove speaker assembly (2).
-
Remove 4 screws and disconnect the speaker harness connector (3).
6. Remove courtesy light lens.
7. Remove 5 screws (1), (3) and pull out the door trim panel at the 6 clip (2) positions.
8. Remove the waterproof sheet.
-
Taking notice of the door harness, peel the waterproof sheet off the door panel carefully.
9. Raise the glass up to the uppermost position, and then remove the rear guide rail.
