X-Type (X400) V6-3.0L (2002)
All fuses are located in the Power Distribution Fuse Box and the Central Junction Fuse Box. Each fuse in the vehicle is identified by a unique "F"
number.
Networks
In most instances, networks are shown as a broken grey line to indicate that there is network communication between the depicted control modules. Refer
to Figures 20.1, 20.2, 20.3 and 20.4 for circuit details.
SCM and CAN Network Messages
This Appendix contains a listing of CAN and SCP Network messages.
The following acronyms and abbreviations are used throughout this section:
A/C
Air Conditioning
ABS
Anti-Lock Braking System
ABSCM
Anti-Lock Braking System Control Module
ABS/TCCM
Anti-Lock Braking / Traction Control Control Module
A/CCM
Air Conditioning Control Module
ACK
Acknowledge
AIRCON
Climate Control
AT Cmd
Commands for configuring and controlling telecommunication devices
AUDIO
Audio Unit
BIT
Smallest element of data code (1 or 0)
BYTE
Grouping of 8 bits (one alphanumeric character)
°C
Degrees Centigrade
CAL
Calibrate
CAN
Controller Area Network
CID
CAN Identifier
CM
Control Module
CONFIG
Configure
D2B OPC
Instructions for translating and routing data for D2B use
D2B
Fiber Optic Network
DIAG
Diagnostics
DSCCM
Dynamic Stability Control Control Module
DTC
Diagnostic Trouble Code
ECM
Engine Control Module
°F
Degrees Fahrenheit
FL
Front Left
FR
Front Right
Gateway
Device that converts messages between different types of networks
GECM
General Electronic Control Module
HLCM
Headlight Leveling Control Module
IC
Instrument Cluster
IDB
Identification Byte
JGM
J Gate Module
Lb. Ft.
Pound Feet (Measure of Torque)
LED
Light Emitting Diode m Meter (length)
MIL
Malfunction Indicator Lamp
ml
Milliliter
ms
Millisecond
MSG
Message
NCM
Navigation Control Module
Nm
Newton Meter (Measure of Torque)
