X-Type (X400) V6-3.0L (2002)
/v6-3.0l/Page-989001.png)
Brake Rotor/Disc: Service and Repair
Front Brake System
Removal
1. Remove the brake pads, For additional information, refer to Brake pad.
2. Remove and discard the brake caliper anchor plate retaining bolts.
3. Detach the brake caliper, brake caliper anchor plate assembly and secure to one side.
