X-Type (X400) V6-3.0L (2002)
Shift Cable: Service and Repair
Cable and Bracket
Removal
1
Move the gear selector lever to "N" position.
.
NOTE: To move the gear selector lever, the ignition must be in the RUN position, with the foot brake pressed.
2. Remove the center console right-hand side trim panel.
3. Remove the gear selector cable locking pin.
