Cherokee 2WD L6-4.0L VIN S (1998)
Floor Duct And Adapter
1. Remove the instrument panel from the vehicle. Refer to: Body and Frame, Interior Trim, Dashboard/Instrument Panel, Service and Repair,
See: Body and Frame/Interior Moulding / Trim/Dashboard / Instrument Panel/Service and Repair
2. Remove the heater-A/C housing from the vehicle. See Heater-A/C Housing for the procedures.
3. Remove the three screws that secure the floor duct and adapter to the heater-A/C housing.
4. Remove the floor duct and adapter from the heater-A/C housing.
5. Reverse the removal procedures to install. Tighten the mounting screws to 2.2 N.m (20 in lbs).
