Cherokee 2WD L6-4.0L VIN S (1998)
Removing/Installing Speedometer Drive Gear
2. Install rotor, spacer (if equipped) and drive gear on output shaft. Then install drive gear snap ring.
3. Apply 1/8 3/16 inch wide bead of Threebond"R" Liquid Gasket TB1281, P/N 83504038, to transmission case sealing surface and install
extension/adapter housing on case.
4. Tighten adaptor housing bolts to 134 Nm (25 ft. lbs.) torque.
5. Install components removed to gain access to rotor and drive gear.
