Cherokee 2WD L6-4.0L VIN S (1998)
Fuel Rail: Description and Operation
FUEL RAIL
Fig. 4 Fuel Rail And Injectors
The fuel rail supplies the necessary fuel to each individual fuel injector and is mounted to the intake manifold (Fig. 4). The fuel pressure regulator
is no longer mounted to the fuel rail on any engine. It is now located on the fuel tank mounted fuel pump module. Refer to Fuel Filter/Fuel
Pressure Regulator in this group for information.
Certain engines are equipped with a fuel pressure test port (Fig. 4). Not all engines are equipped with this test port.
NOTE: The fuel rail is not repairable.
