Grand Cherokee 2WD V8-4.7L VIN J (2004)
Fig. 24 Right Multi-Function Switch Remove/Install
6. Remove the two screws that secure the right multi-function switch to the multi-function switch mounting housing.
7. Remove the right multi-function switch from the multi-function switch mounting housing.
INSTALLATION
1. Position the right multi-function switch onto the multi-function switch mounting housing.
2. Install and tighten the two screws that secure the right multi-function switch to the multi-function switch mounting housing. Tighten the screws to
2.5 Nm (22 in. lbs.).
3. Reconnect the instrument panel wire harness connector for the right multi-function switch to the switch connector receptacle.
4. Position the lower tilting steering column shroud to the underside of the steering column.
5. Install and tighten the screw that secures the lower tilting steering column shroud to the multi-function switch mounting housing. Tighten the screw
to 2 Nm (17 in. lbs.).
6. Position the upper tilting column shroud over the steering column with the hazard warning switch button inserted through the hole in the upper
surface of the shroud.
7. Align the snap features on the upper and lower shrouds and apply hand pressure to snap them together.
8. Reconnect the battery negative cable.
