Powertrain Control Module <--> [Engine Control Module]|Service and Repair > < Powertrain Control Module <--> [Engine Control Module]|Diagrams|Connector Views|Page 3234

Grand Cherokee 4WD V8-4.7L (2003)

Page 1
background image

Powertrain Control Module: Testing and Inspection

Test 1 - 3

SYMPTOM

CHECKING THE PCM POWER AND GROUNDS

POSSIBLE CAUSES

-

(A7) PCM fused B+ circuit

-

(F991) PCM fused ignition switch output circuit

-

(Z81,Z82) PCM ground circuits
