Grand Cherokee 4WD Laredo V8-4.7L (2002)
5. Remove the three bolts and remove the control assembly. (Fig. 13)
INSTALLATION
1. Install the control assembly.
2. Install the three bolts and tighten to 10 N.m (90 in. lbs.).
3. Connect the outside handle link.
4. Connect the latch cables.
5. Connect the electrical connector.
6. Adjust the outside handle.
7. Adjust the latch cables.
8. Install the liftgate insulator pad.
