Patriot 4WD L4-2.4L (2009)
CAUTION: When installing the oil pan, align the dowel pin of the transaxle case with the dowel pin hole of the oil pan.
10. Install the oil pan on the transaxle case (1). Install and tighten the mounting bolts to 8 Nm (70 in.lbs.).
NOTE: Only transmission fluid of the type labeled Mopar(R) CVTF+4 (Automatic Transmission Fluid) should be used in this transaxle.
11. Check the oil level See: Check Oil Level
