Sorento 2WD V6-3.3L (2008)
25. Remove crankshaft sprocket(A)(LH camshaft drive).
26. Remove tensioner adapter assembly(A).
Reassembly
REASSEMBLY
1. The key(A) of crankshaft should be aligned with the timing mark(B) of timing chain cover. As a result of this, the piston of No.1 cylinder is placed
at the top dead center on compression stroke.
2. Install tensioner adapter assembly(A).
3. Install crankshaft sprocket(A)(LH camshaft drive).
