BATTERY CONDITION - Td5
Remove
1. Remove drivers seat base.
2. Release clip securing battery cover.
3. Remove battery cover.
NOTE: The vehicle may be fitted with an
alarm and immobilisation system. To
prevent the alarm from sounding, it is
important that the following procedure is used
when disconnecting the battery.
4. Turn the ignition switch to position ’II’, and then
to position ’0’.
5. Remove the ignition key.
6. Disconnect the vehicle -ve terminal within 15
seconds.
NOTE: Always disconnect the -ve terminal
first. When replacing, connect the +ve
terminal first.
Check
The battery fitted to Td5 models is designed to be
maintenance free, so topping-up is not possible. On
the top of the battery is a battery indicator. When the
indicator shows:
•
GREEN - The battery is in a good state of charge.
•
DARK (turning to black) - The battery needs
charging.
•
CLEAR (or light yellow) - The battery needs
replacing. Do not charge the battery or jump start
the vehicle in this condition.
•
If the green dot is missing, the battery needs
charging.
NOTE: If the indicator shows clear or
yellow, tap the indicator with the handle of
a screwdriver to disperse any air bubbles.
If the indicator colour remains unchanged, the
battery will need replacing.
Refit
7. Clean and grease battery terminals and leads
with petroleum jelly.
8. Connect leads to battery (+ve first) and tighten
clamp bolts.
9. Fit battery cover and secure with clip.
10. Fit drivers seat base.
